2016 TM302BM MST
TM302BM in Mustard Red copyright sprite

The TM302BM is a Talman series solid body electric guitar model introduced by Ibanez in 2016. It was produced in China.

The TM302BM features an alder body bolted to a maple neck with a 22-fret maple fingerboard with black dot position markers. Components include a Telecaster-style IFX10 fixed bridge with six independent saddls, dual Ibanez Custom Vintage single coil pickups mounted in a black pickguard, a bone nut and locking tuners.

Design elements

The headstock of the TM302BM features a straight-pull design, which allows the strings to come straight off the bone nut, eliminating the need for a string tree or a tilt-back design. The fretboard has a 12" (305mm) radius meaning it is flatter compared to traditional styled guitars from other brands which enhances the player's ability to bend notes and allows for a lower string action. The Fast Action neck joint improves access to the upper frets.

Related models

The TM302M (white pickguard) and TM302PM (pearloid pickguard) are similar models, except for the color of the pickguard, knobs and finish.

The TM302BM was discontinued after 2017 along with all but a couple of Talman models.

Specifications

Specifications for TM302BM
Model name: TM302BM
Year(s) produced: 2016–2017
Sold in: USA
Made in: China
Finish(es): Mustard (MST)
Body
Body type:
Solid body
Body material:
Alder
Neck joint:
Fast Access
Bridge:
IFX10 fixed
Pickguard:
Black
Hardware color:
Nickel/ black knobs
Neck
Neck type:
Talman Classic-Plus
Neck material:
1-piece maple
Scale length:
648mm/ 25½"
Fingerboard material:
Maple
Fingerboard inlays:
Black dot
Frets:
22 / medium
Nut:
Bone
Machine heads:
Locking
Electronics/ Strings
Pickup configuration:
SS
Bridge pickup:
Custom Vintage Single (S)
Neck pickup:
Custom Vintage Single (S)
Controls:
Master volume / master tone / 3-way toggle
String gauge (factory):
.010–.046
