TAM100 zoom
TAM100 with quilted blue maple top Red copyright sprite

The TAM100 is an eight-string solid body electric guitar model introduced by Ibanez for 2013. It is a signature model of guitarist Tosin Abasi of the American progressive metal band Animals as Leaders. It was made in Japan by FujiGen.

The TAM100 features a AAA quilted maple top on a basswood body bolted to a wenge and bubinga neck with a 24-fret wenge fingerboard with mother of pearl block position markers. Components include DiMarzio Ionizer 8 pickups with two humbuckers (which can be coil-split) flanking a single-coil, a fixed bridge with a locking nut and Gotoh tuning machines. It is based on the RG2228.

The TAM10 is a less expensive mass market version of this guitar.

The TAM100 was discontinued in 2017 when Abasi left Ibanez to start his own guitar brand.

Specifications[]

Specifications for TAM100
Model name: TAM100
Year(s) offered: 2013–2017
Sold in: Americas & Oceania 2013–2016 / Asia & Africa 2013–2016 / China 2013–2016 / Europe 2013–2016 / Japan / USA 2013–2016
Made in: Japan
Price: MSRP: ¥525,000 (2013) / US$5,333.32 (2014) • SMAP: ¥500,000 (2013) / US$3,999 (2014)
Finish(es): Transparent matte light blue top w/ unpainted back and sides
Body
Body type:
Solid body
Body material:
Basswood body (36mm) w/ 4mm AAA quilted maple top and quilted binding
Neck joint:
AANJ
Bridge:
2013: FX Edge II-8 fixed
2014–2017: FX Edge III-8 fixed
Pickguard:
Tortoise shell
Hardware color:
Gold
Neck
Neck type:
TAM8
Neck material:
5-piece wenge/ bubinga w/ KTS titanium rods
Scale length:
686mm/ 27"
Fingerboard material:
Wenge
Fingerboard inlays:
Mother of pearl block
Frets:
24 / jumbo (Prestige edge treatment)
Nut:
Locking (55mm)
Machine heads:
Gotoh SG381
Electronics/ Strings
Pickup configuration:
HSH
Bridge pickup:
DiMarzio Ionizer 8 bridge (H)
Middle pickup:
DiMarzio Ionizer 8 middle (S)
Neck pickup:
DiMarzio Ionizer 8 neck (H)
Controls:
Master volume / master tone / 5-way lever pickup selector / coil-split toggle
Output jack:
¼" stereo barrel (side mounted)
String gauge (factory):
.010/.013/.017/.030/.042/.054/.064/.074
Factory tuning:
1E 2B 3G 4D 5A 6E 7B 8E
