SR600L

SR600L Transparent Black

The SR600L is a left-handed Soundgear series solid body electric bass model introduced by Ibanez for 1998. It was produced in Japan by FujiGen as part of the Standard line.

The SR600L features a double-cutaway light ash body bolted to a maple neck with a 24-fret rosewood fingerboard with pearl dot position markers and a matching headstock. Components include a pair of IBZ J/P-1 pickups channeled through an Active 2-band EQ, a Die-cast 4 string fixed bridge with 19mm string spacing, black hardware and die-cast machine heads.

The SR600 is a standard version.

The SR600L was only offered in 1998.

Specifications[]

Related content: Left-handed bass models | Soundgear series |

Specifications for SR600L

Model name: SR600L

Year(s) offered: 1998

Sold in: Japan

Made in: Japan

Price: SMAP: JP¥ 78,000 (1996)

Finish(es): Transparent Black(TK)

Body

Body type:
Solid body

Body material:
Light Ash

Neck joint:
AANJ

Bridge:
Standard IV string (19mm string spacing)

Knob style:
Knurled metal dome (black)

Hardware color:
Black

Neck

Neck type:
SR4

Neck material:
1-piece maple

Scale length:
864mm / 34"

Fingerboard material:
Rosewood

Fingerboard inlays:
Pearl dot

Frets:
24 / medium

Nut:
Black plastic (43mm)

Machine heads:
Die-cast

Factory tuning:
1G,2D,3A,4E (E standard)

Electronics

Pickup configuration:
JP

Bridge pickup:
IBZ J1

Neck pickup:
IBZ P1

Electronics:
Active 2-band EQ

Controls:
Volume / balance / two-band EQ (bass & treble boost-cut)

Battery:
9V

Output jack:
¼" mono (side mounted)

About this table

Sources[]

1998 Japan catalog (p. 32-33)
