2018 RG7570 BRE
RG7570 Black Rutile Red copyright sprite

The RG7570 is an RG series solid body electric guitar model introduced by Ibanez in late 2017. It is made in Japan by FujiGen as part of the J Custom line.

The RG7570 features a AAA flamed maple top with natural binding on an American basswood body bolted to a maple and wenge neck with ultra-thin Super Wizard profile and Velvetouch treatment and a 24-fret Macassar ebony fingerboard with abalone dot position markers only at the twelfth fret. Components include DiMarzio pickups with a pair of Fusion Edge humbuckers flanking a Black Velvet single-coil, a Lo-Pro Edge double locking tremolo bridge, a locking nut, an angled output jack and Gotoh tuning machines and strap locks.

For 2020 the fretboard was changed to Kalimantan ebony.

The RG7570Z is a similar model with an Edge Zero tremolo and some other small differences. The RG7527 is a related 7-string model.

The RG7570 was discontinued after 2020.

Specifications[]

Related content: J Custom series | RG series | Models-icon
Specifications for RG7570
Model name: RG7570
Year(s) offered: 2017–2020
Sold in: Japan
Made in: Japan
Finish(es): Black Rutile (BRE)
Body
Body type:
Solid body
Body material:
American basswood w/ 4mm AAA flamed maple top w/ natural binding
Neck joint:
AANJ
Bridge:
Lo-Pro Edge tremolo (10.8mm string spacing)
Strap buttons:
Gotoh Free Lock II
Knob style:
Gotoh VK1-19 (knurled metal dome)
Hardware color:
Cosmo black
Neck
Neck type:
RG J Custom Super Wizard
Neck material:
5-piece maple/ wenge
Scale length:
648mm/ 25½"
Fingerboard material:
2017–2019: Macassar ebony
2020: Selected Kalimantan ebony
Fingerboard inlays:
2017–2019: Abalone dots at 12th fret
2020: Mother of pearl dots at 12th fret
Frets:
24 / medium (j.custom edge treatment)
Nut:
Top-Lok III (48mm)
Machine heads:
Gotoh SG381
Electronics/ Strings
Pickup configuration:
HSH
Bridge pickup:
DiMarzio Fusion Edge bridge (H) passive/ ceramic
Middle pickup:
DiMarzio Black Velvet middle (S) passive/ alnico
Neck pickup:
DiMarzio Fusion Edge neck (H) passive/ ceramic
Controls:
Master volume / master tone / 5-way lever pickup selector
Output jack:
¼" stereo barrel
String gauge (factory):
.009/.011/.016/.024/.032/.042 (D'Addario EXL120)

Images[]

Additional details
HSH 5-way both-splits
Pickup switching
Controls VT5
Control layout
