2019 EWP14 OPN 2Y 05
EWP14 Open Pore Natural Red copyright sprite

The EWP14 is an EWP series acoustic piccolo guitar model introduced by Ibanez for 2016. It is made in China. It is also sold packaged with a gig bag as the EWP14WB.

The EWP14 features a tenor-style EW shape with a soft Florentine cutaway and a laminated ovangkol top on ovangkol back and sides with an open pore finish. The round soundhole has an abalone rosette. It has a mahogany neck with a 19-fret rosewood fingerboard with maple dot position markers. Components include an ivory plastic saddle in a rosewood bridge, a plastic nut and chrome die-cast tuning machines.

For 2018 the rosewood fretboard and bridge were changed to purpleheart. For 2019 the mahogany neck was replaced with okoume.

The EWP13 is a similar model with a Macassar ebony body. The EWP32FM is a similar model with a flamed maple top and sapele back.

Specifications

Specifications for EWP14
Name: EWP14 / EWP14WB
Years: 2016–2020
Areas: Asia & Africa / China / Europe / Japan / North & South America and Oceania / USA
Made in: China
Finishes: Open Pore Natural (OPN)
Body
Body type:
Acoustic
Body shape:
Tenor-style EW w/ soft Florentine cutaway
Dimensions:
  Length: 305mm/ 12"
  Width: 238mm/ 9⅜"
  Depth: 70mm/ 2¾" (60mm at neck joint)
Top:

  Material: Ovangkol (laminated)
  Finish: Open pore
  Binding: Black & white multi

Back/sides:

  Material: Ovangkol
  Finish: Open pore

Soundhole shape:
Round
Soundhole rosette:
Abalone
Neck
Neck profile:
EWP
Neck material:
2016–2018: 1-piece mahogany
2019–2020: 1-piece okoume
Neck joint:
14th fret
Scale length:
432mm/ 17"
Fingerboard:
2016–2017: Rosewood
2018–2020: Purpleheart
Inlays:
Maple dot
Frets:
19
Nut:
Ivory plastic (42mm)
Machine heads:
Ibanez die-cast 1:15 ratio
Components
Bridge:
2016–2017: Rosewood
2018–2020: Purpleheart (9.6mm string spacing)
Bridge pins:
Ibanez Advantage (black w/ white dot)
Saddle:
Ivory plastic (74mm)
Hardware color:
Chrome
Strings (factory):
.010/.014/.023/.030/.039/.047 (Extra light gauge phosphor bronze)
Factory tuning:
1A,2E,3C,4G,5D,6A
