2013 ASR70 VB 12 01
ASR70 Vintage Burst Red copyright sprite

The ASR70 is an Artcore series hollow body electric guitar model introduced by Ibanez for 2013. It was produced in China.

The ASR70 features a double-cutaway, full-hollow body design with an arched laminated maple top with ƒ holes and ivory binding on maple back and sides mated to a set-in mahogany neck with a 22-fret rosewood fingerboard with ivory binding and acrylic block markers. Components include a pair of Ibanez Artcore dog ear style P90 single coil pickups, a Tune-o-matic style bridge with trapeze tailpiece, a plastic nut, Sure Grip III knobs, and Ibanez tuning machines.

For 2015 the Artcore pickups were replaced with Classic Elite P9Ds and the pearl block fretboard inlays were switched to acrylic.

The ASR70 was discontinued after 2015.

Specifications[]

Related content: Artcore series | Models-icon
Specifications for ASR70
Year(s) offered: 2013–2015
Sold in: Asia / Europe / Japan / North America / USA
Made in: China
Finish(es): Vintage Burst (VB)
Body
Body type:
Hollow body
Dimensions:
  Length: 489mm / 19¼"
  Width: 400mm / 15¾"
  Depth: 44.45mm / 1¾" (incorrectly listed as 67mm / 2⅝")
Top:
  Material: Maple (laminated)
  Binding: Ivory
Back/sides:
  Material: Maple (laminated)
Neck joint:
Set-in
Bridge:
ART-1
Tailpiece:
VT06 trapeze
Knob style:
Sure Grip III (black)
Hardware color:
Chrome
Neck
Neck type:
Artcore
Neck material:
1-piece mahogany
Scale length:
628mm/ 24¾"
Fingerboard material:
Rosewood w/ ivory binding
Fingerboard inlays:
2013–2014: Pearl block
2015: Acrylic block
Frets:
22 / medium
Nut:
Ivory plastic (43mm)
Machine heads:
Ibanez die-cast
Electronics/ Strings
Pickup configuration:
SS
Bridge pickup:
2013–2014: Ibanez ACH-DS2 (S)
2015: Ibanez Classic Elite P9D (H)
Neck pickup:
2013–2014: Ibanez ACH-DS1 (S)
2015: Ibanez Classic Elite P9D (H)
Controls:
Master volume / master tone / 3-way toggle pickup selector
Output jack:
¼" mono (side mounted)
String gauge (factory):
.010/.013/.017/.030/.042/.052
Factory tuning:
1E,2B,3G,4D,5A,6E (E Std.)

Images[]

Additional finishes/ details
SS 3-way
Pickup switching
Controls 2V2T3
Control layout
