AR3212 Vintage Burst (more images)

The AR3212 is a 12-string Artist series solid body electric guitar model introduced by Ibanez in mid-2013. It is produced in China and was a spot model which never appeared in a catalog.

The AR3212 features an arched flame maple top with abalone purfling and cream binding on a mahogany body mated to a set-in maple neck with a 22-fret fingerboard with binding and split block position markers. Components include a pair of Ibanez Super 58 Custom humbucking pickups with individual volume and tone controls wired to Tri-sound switches which allow a range of tone options, a Tune-O-matic style 12-string bridge and tailpiece, Ibanez die-cast tuning machines, and Sure Grip III knobs.

The AR320 is a similar six string model.

The AR3212 was produced only in 2013.

Specifications[]

Related content: Artist series |
Specifications for AR3212
Model name: AR3212
Year(s) offered: 2013
Sold in: USA
Made in: China
Price: SMAP: US$699.99[1]
Finish(es): Cherry Sunburst (CRS) / Vintage Burst (VB)
Body
Body type:
Solid body
Body material:
Mahogany w/ flamed maple top, abalone purfling & cream binding
Neck joint:
Set-in
Bridge:
12-string Tune-o-matic
Tailpiece:
Tailpiece for 12-string
Knob style:
Sure Grip III
Hardware color:
Gold
Neck
Neck type:
AR
Neck material:
3-piece maple
Scale length:
628mm/ 24¾"
Fingerboard material:
Rosewood w/ binding
Fingerboard inlays:
Pearl/ abalone split block
Frets:
22 / medium
Nut:
Ivory plastic (43mm)
Machine heads:
Ibanez die-cast
Factory tuning:
1E,2B,3G,4D,5A,6E (E Std.)
Electronics
Pickup configuration:
HH
Bridge pickup:
Ibanez Super 58 Custom bridge (H)
Neck pickup:
Ibanez Super 58 Custom neck (H)
Controls:
Two volumes / two tones / 3-way toggle pickup selector / two Tri-sound switches
Output jack:
¼" mono / side mounted

Images[]

Other available finishes
Cherry Sunburst
Additional details
Pickup switching
Controls layout

Sources[]

  1. AR3212 product listing, Musician's Friend (US retailer), archived November 2013
