Missing image (An image is wanted for this article. You can help by finding and adding it) Red copyright sprite.png

The AR305GR is an Artist series solid body electric guitar model introduced by Ibanez in 1983. It was made in Japan by FujiGen.

The AR305GR is specially equipped for use with a Roland GR-300 guitar synth. It has a bound dish carved mahogany burl top on a double-cutaway mahogany body mated to a set-in three-piece maple neck with a 22-fret ebony fingerboard with binding and pearl and abalone split block position markers. Components include a pair of Ibanez Super 58 humbucking pickups with individual volume and tone controls, a Tune-o-matic style Gibraltar bridge with embedded sustain block and tailpiece, VelveTune II machine heads and Sure Grip II knobs.

Very little is know about this model aside from the single advertisement shown below. If you have any information on this guitar, please add them or contact a wiki admin.

The AR300GR is a similar model with a flame maple top. The AR305 (1982–1987) is a similar model without the Roland synth componentry.

It's believed the AR305GR was produced only in 1983 in very limited numbers and sold only in Japan.

Specifications

Specifications for AR305GR
Model name: AR305GR
Year(s) produced: 1983
Sold in: Japan
Made in: Japan
Finish(es): Antique Violin (AV)
Body
Body type:
Solid body
Body material:
Mahogany w/ mahogany burl top w/ binding
Neck joint:
Set-in w/ smooth heel
Bridge:
Gibraltar II
Tailpiece:
Quik Change II w/ "cloud" ornament
Knob style:
Sure Grip II
Hardware color:
Gold
Neck
Neck type:
AR
Neck material:
3-piece rock maple
Scale length:
628mm/ 24¾"
Fingerboard material:
Ebony w/ binding
Fingerboard inlays:
Pearloid & abalone split block
Frets:
22 / medium
Nut:
Bone
Machine heads:
Ibanez VelveTune II
Electronics/ Strings
Pickup configuration:
HH + piezo
Bridge pickup:
Ibanez Super 58 (H)
Neck pickup:
Ibanez Super 58 (H)
Controls:
Two volumes / two tones / 3-way toggle pickup selector / 2 Tri-sound switches / unknown synth controls
Factory tuning:
1E,2B,3G,4D,5A,6E (E Std.)

Images

Additional details
HH 3-way tri-sound.png
Pickup switching diagram
AR300GR-AR305GR 1983.jpg
AR300GR & AR305GR advertisement from Guitar magazine (Japan), August 1983[1]
Wimage.jpg An image for this article is missing!
An image of the AR305GR Antique Violin (AV) is wanted for this article. You can help by finding, uploading and adding it!

Sources

  1. Secret back room #15, Our ARs (Artist registry), archived October 2018
