The AR2800 is a double neck Artist series solid body electric guitar model introduced by Ibanez in 1983. It was made in Japan by FujiGen and was a spot model that may have been available exclusively from Kurosawa Gakki in Japan.

The AR2800 has both a six string and twelve string neck. It features an arched maple top on a German carved double-cutaway body mated to a pair of set-in three-piece rock maple necks with 22-fret ebony fingerboards with binding and pearloid and abalone split block position markers. Components include a pair of Ibanez Super 58 humbucking pickups for each neck mounted in cream pickup rings with individual volume and tone controls, a pair of Gibraltar II Tune-O-Matic style bridges and special stop tailpieces with integrated scalloped plates, rubberized Sure Grip control knobs, Smooth Tuner machine heads and individual outputs for each neck.

The 2670 (a.k.a. "Artwood Twin") and AR1200 (a.k.a. Artist Twin) are related Artist series double neck guitars.

The AR2800 was produced in very limited numbers only in 1983.

Specifications[]

Related content: Artist series | Models-icon
Specifications for AR2800
Year(s) offered: 1983
Sold in: Japan
Made in: Japan
Finish(es): Polar White (PW)
Body
Body type:
Solid body
Body material:
Mahogany w/ maple top
Neck joint:
Set-in w/ smooth heel (both necks)
Bridge:
Gibraltar II
Tailpiece:
Special tailpiece w/ integrated scalloped ornament
Knob style:
Sure Grip II
Hardware color:
Gold
Neck
Neck type:
AR
Neck material:
3-piece rock maple (both necks)
Scale length:
628mm/ 24¾"
Fingerboard material:
Ebony w/ binding
Fingerboard inlays:
Pearloid & abalone split block
Frets:
22 / medium (both necks)
Nut:
Half-bone/ half-brass (both necks)
Machine heads:
Smooth Tuner
Electronics
Pickup configuration:
HH
Bridge pickup:
Ibanez Super 58 (H) (both necks)
Neck pickup:
Ibanez Super 58 (H) (both necks)
Controls:
6-string: Master volume / master tone / 3-way toggle pickup selector / two mini-toggle Tri-sound switches
12-string: Master volume / master tone / 3-way toggle pickup selector / two mini-toggle Tri-sound switches
Both: 3-way neck selector (6 string/ both/ 12 string) / master volume

Images[]

Additional details
1983 AR1200 controls
Controls
AR2800PW KurosawaGakki
Ad from Kurosawa Gakki[1]
Wimage An image for this article is missing!
An image of the AR2800 Polar White (PW) is wanted for this article. You can help by finding, uploading and adding it!

Sources[]

  1. Mysterious AR2800, Our ARs (Artist registry), archived March 2015
